Art.
TCRF PANTOGRAFOC

SCISSOR HIGH LIFT PALLET TRUCK

TCRFPANTOGRAFOC  can raise a load of maximum 1.000 Kg to a working height of 800mm.
Its frame height has been reduced in order to allow an easy acces to the raised load. The cam locking device automatically activates when a lifting height greater than mm 200 is reached.
The quick lift system requires only 20 strokes to reach full height: this works only for loads with a weight lower than 350 kg





TECHNICAL SPECIFICATIONS

Capacity

Kg 1.000
Weight   Kg 11

Overall fork length

L mm 1.140

Width overall forks

mm 530

Total length

L1 mm 1.480

Lowered height

mm 85

Stroke height (the load can be stopped at any height within the stroke height)

mm 715

Raised height

mm 800

Nylon steer wheel

mm 150

2 white nylon front roller

mm 50

Steer arc degrees 180

Turning radius

Wa mm 1.250

Working aisle for europallet 800x1.200

Ast mm 1.760
Weight Kg 149

3 positions fingertip control (lifting-lowering-quicklifting)

Heavy gauge steel construction with continuous seam welds

Oven dried epoxy powder painting
